MBCI Insulated Panels

Information
Eco-ficient Insulated BattenLok
Eco-ficient Insulated R Panel

Eco-ficient Insulated Roof Panels

MBCI offers two distinctive insulated roof panels: Insulated BattenLok and the Insulated R Panel. Eco-ficient Insulated BattenLok is a variation of our popular single-skin standing seam roof offering with the added benefits of being an insulated metal panel in wider widths. Likewise, Eco-ficient Insulated R Panel is the insulated version of the popular single skin PBR panel. Insulated roof panels offer quick and easy installation. MBCI has the knowledge to assist you with the proper equipment needed for installation to help reduce installation times. MBCIs insulated roof panels have gone through rigorous testing to ensure their ability to perform as designed.

Eco-ficient Insulated BattenLok

The Eco-ficient Insulated BattenLok is one of MBCIs popular standing seam metal roof offerings. The Eco-ficient Insulated BattenLok roof panel is ideal for architectural, commercial, industrial, institutional and cold storage applications. The exterior profile has a 2-inch high standing seam with a Mesa profile. The interior profile is also a stucco-embossed Mesa pattern. Eco-ficient Insulated BattenLok is attached to a building structure with concealed clips to provide continuous insulation and eliminate thermal bridges.

Eco-ficient Insulated BattenLok Product Information

  • Coverage Width 42 (standard); 30, 36 (optional)
  • Thicknesses 2, 2 , 3, 4, 5, 6
  • Lengths Recommended maximum is 50 Panel
  • Attachment Concealed Fastening System Panel
  • Exterior Gauge 24, 22
  • Interior Gauge 26, 24, 22
  • Exterior Finishes Stucco-embossed
  • Interior Finishes Stucco-embossed
  • Exterior Coatings Signature 200, Signature 300
  • Interior Coatings USDA White (standard)

Colors
BlackBuckskinBurgundyBurnished Slate
Charcoal GrayCrimison RedDesert SandFern Green
Gallery BlueGrayHawaii BlueIvory
Ivy GreenKoko BrownLight StoneMarine Green
Polar WhiteRegal WhiteRustic RedSaddle Tan

MBCI Warranties

MBCI offers both finish warranties and weather-tightness warranties. The finish warranties include the Bare Galvalume and Galvalume Plus Warranty, the Signature 200 and Signature 300 paint warranties and a Technical Bulletin about Saltwater and Marine Atmospheres.

MBCI offers several different types of weather-tightness warranties and was the first company in the metal roofing industry to offer a Single Source warranty. Single Source Warranties put the complete burden for proper installation of the roof system* on MBCI from the date of substantial completion. MBCI offers three levels of Single Source Warranties depending on the level of project the building owner requires.

*Roof system is defined as the MBCI furnished roof panels, flashing and related items used to fasten the roof panels and flashing (including roof jack and curb attachments pre-approved in writing by MBCI) to the roof structure.

Eco-ficient Insulated R Panel

MBCIs Eco-ficient Insulated R Panel offers the same versatility as the single-skin PBR panel and can be used for both roof and wall applications. The Eco-ficient Insulated R Panel utilizes a through-fastened attachment. The standard exterior skin is smooth but can be embossed if requested. The interior skin of the Eco-ficient Insulated R Panel is roll formed with our standard stucco-embossed Mesa profile. The Insulated R Panel is ideal for commercial applications.

Eco-ficient Insulated R Panel Product Information

  • Coverage Width 36
  • Thicknesses 1 , 2, 2 , 3, 4, 5, 6
  • Lengths Recommended maximum is 40 Panel
  • Attachment Exposed Fastening System Panel
  • Exterior Gauge 26, 24, 22
  • Interior Gauge 26, 24, 22
  • Exterior Finishes Smooth; Embossed
  • Interior Finishes Stucco-embossed
  • Exterior Coatings Signature 200, Signature 300, Applied Finishes (for wall applications only)
  • Interior Coatings USDA White (standard)

Colors
BlackBuckskinBurgundyBurnished Slate
Charcoal GrayCrimison RedDesert SandFern Green
Gallery BlueGrayHawaii BlueIvory
Ivy GreenKoko BrownLight StoneMarine Green
Polar WhiteRegal WhiteRustic RedSaddle Tan

MBCI Warranties

MBCI offers both finish warranties and weather-tightness warranties. The finish warranties include the Bare Galvalume and Galvalume Plus Warranty, the Signature 200 and Signature 300 paint warranties and a Technical Bulletin about Saltwater and Marine Atmospheres.

MBCI offers several different types of weather-tightness warranties and was the first company in the metal roofing industry to offer a Single Source warranty. Single Source Warranties put the complete burden for proper installation of the roof system* on MBCI from the date of substantial completion. MBCI offers three levels of Single Source Warranties depending on the level of project the building owner requires.

*Roof system is defined as the MBCI furnished roof panels, flashing and related items used to fasten the roof panels and flashing (including roof jack and curb attachments pre-approved in writing by MBCI) to the roof structure.
